PowerGem Plus
Battery
About
PowerGem Plus
The HINAESS PowerGem Plus Battery is a high-capacity, ultra-safe energy storage solution designed to enhance both residential and commercial solar energy systems. Utilizing advanced LFP (Lithium Iron Phosphate) materials, the PowerGem Plus ensures robust and reliable performance with a long lifespan. This battery is engineered for flexibility, offering compatibility with a wide range of inverters and supporting up to 32 units in parallel without the need for extra devices. With its smart Battery Management System (BMS) and multiple protection features, the PowerGem Plus is designed for efficient energy management and optimal safety.
The HINAESS PowerGem Plus Battery is engineered to provide reliable and efficient energy storage, making it an excellent choice for optimizing solar power systems. Its advanced features and robust construction ensure long-term performance and safety, catering to diverse energy needs with ease.
Specifications
- Cell Type: LFP (Lithium Iron Phosphate)
- Rated Power: 14.3 kWh
- Rated Capacity: 280 Ah
- Rated Voltage: 51.2 V
- Charge Voltage: 56.5 V
- Max Charge Current: 140 A (continuous), 150 A (start limit current to 10A, retest every 10 minutes), 160 A (peak1 15S), 180 A (peak2 500ms)
- Max Discharge Current: 140 A (continuous), 150 A (start giving over-current alarm but not stop discharging), 160 A (peak1 5 minutes), 200 A (peak2 500ms)
- Parallel: Up to 32 units parallelable without extra device needed; slave battery drops offline or comes back alive without affecting system running
- IP Level: IP20
- Dimensions (WxDxH): 900x475x238 mm
- Weight: 115 kg
- Communication: CAN/RS485
- Compatible Inverter: Victron, Luxpower, Deye, Voltronic, SMA, Goodwe, Growatt, Sofar, Solark, SRNE, Must
- Depth of Discharge (DOD): 90%
- Cycles: 8000 (@ 25℃, 90% DOD, 0.5C testing condition)
- Warranty: 10 years
- Humidity: 5%~85% RH (No condensation)
- Working Temperature: -20℃ ~ +55℃
- Storage Temperature: -10℃ ~ +35℃
- Remote Maintenance: Flexible remote upgrade with original firmware backup to prevent upgrade failure
- Protection: Overcharge/discharge/current/voltage/temperature protection, short circuit protection, reverse connection protection, charge balance, low SOC protection
- Certification: CE, UN38.3, IEC62619
Features:
- Ultra-Safe LFP Material: Ensures high safety and long lifespan.
- Short Circuit Protection: Protects the battery from damage due to short circuits.
- Flexible Remote Upgrade: Allows for remote monitoring and updates, maintaining optimal performance.
- Wide Range Inverter Compatibility: Compatible with major inverter brands for versatile applications.
- Multiple Protections: Includes protections against overcharge, over-discharge, over-current, over-voltage, and temperature anomalies.
- Smart BMS Management: Enhances battery life and performance through intelligent management.
- Active Balancing Charging: Ensures uniform charging and discharging across all cells.
- Low Self-Consumption: Reduces energy loss during storage.
